How Emissivity Works
Emissivity is the measure of how well a surface absorbs and re-emits radiant energy, on a scale from 0 to 1, where 1 is a perfect black body. In any fired asset, high-emissivity surfaces send heat back into the product; low-emissivity surfaces let it leave with the flue gas. Emisshield coatings raise a surface's emissivity to 0.85 to 0.95 and hold it constant to 3,100°F (1,700°C), which is why a 2 to 4 mil layer produces double-digit fuel effects in documented installations.
01
What is emissivity?
Emissivity describes how efficiently a surface radiates energy compared with a theoretical perfect emitter, a black body, which scores exactly 1.0. Every surface above absolute zero radiates. A polished metal sits near 0.1; oxidized steel near 0.6; refractory brick near 0.4; ceramic fiber near 0.3.
Two things matter in practice. The value itself: higher means the surface absorbs and re-emits more radiant energy instead of reflecting it. And stability with temperature: most materials lose emissivity as they heat up, exactly when the process needs it most. A true high emissivity material holds its value at operating temperature.
02
What is a high emissivity material?
A high emissivity material is one whose surface emissivity stays near black-body behavior (0.85 or above) at working temperature. Common construction materials for thermal equipment are not high emissivity materials: ceramic fiber (~0.3), refractory (~0.4), and metals (~0.6) all reflect a large share of incident radiation, and their values fall further as temperature rises. Emisshield coating systems convert those surfaces into high emissivity materials, raising them to 0.85 to 0.95 and keeping them there to 3,100°F.
03
What happens inside a thermal asset without a high emissivity coating?
Burners release energy as radiation and hot gas. Ideally that energy lands in the product: the steel slab, the glass melt, the process tube, the boiler waterwall, the ware in a kiln. In reality, low-emissivity walls reflect part of the incident radiation back into the flue gas stream, where it exits the stack as waste. Hot spots form where heat concentrates, cold zones stretch cycles, and the control system compensates the only way it can, by burning more fuel.
04
How does a high emissivity coating change that?
Emisshield converts the lining or component from a passive reflector into an active re-radiator. Three things happen in sequence.
Emisshield is an emissivity enhancer, not an insulator. Insulation slows heat leaving through the wall by conduction. Emisshield changes what happens to radiant energy inside the chamber. Fired equipment needs both.
/ 01
Absorb
The ceramic matrix absorbs radiant energy from the burners and convective energy from hot flue gases across a wide band of wavelengths.
/ 02
Re-radiate
It re-emits that energy, spectrally redistributed across broader wavelengths, toward the coolest mass in the enclosure. Radiant exchange inherently favors the coolest surface, which is the product load.
/ 03
Perform
More of every BTU reaches the load. Fuel drops, throughput rises, tube and wall temperatures even out, and hot spots fade.
05
What is spectral redistribution and why does it matter in gas-fired equipment?
Flue gases (water vapor and CO2) absorb radiation strongly in specific wavelength bands and are nearly transparent in others. Energy re-emitted in the absorbing bands is captured by the gas and carried up the stack; energy re-emitted in the transparent bands passes through to the process surface. Emisshield absorbs incident energy and re-emits it across a broader spectrum, so a larger share of the radiant energy bypasses re-absorption by the flue gas and reaches the load. This is the mechanism behind the fuel reductions documented in gas-fired heaters, boilers, dryers, and kilns.
06
Why does Emisshield perform as a gray body?
Most surfaces lose emissivity as temperature rises and emit unevenly across wavelengths. Emisshield is engineered to perform as a gray body: emissivity that holds essentially constant across temperature and wavelength, to 3,100°F. Its nanostructured formulation packs particles of varied sizes into a dense structure (filling a container with volleyballs, marbles, peas, and sand), which is the configuration behind its sustained emissivity and heat re-radiation. See gray body and spectral redistribution in the Glossary.
07
What does that do to the equipment itself?
Beyond fuel, the same mechanism changes surface conditions on the coated asset. Documented effects across the case study library include tube-wall temperatures reduced by 40 to 70°C in fired heaters, which slows creep, oxidation, and coke formation; ceramic fiber shrinkage held under 1% against 5 to 7% for uncoated fiber; more uniform radiant flux across walls and tubes, which reduces flame impingement and localized overheating; and lower exterior shell temperatures. Each figure is sourced in its own case study.
08
What results does that produce?
Across 500+ coated facilities: up to 15% fuel savings, 5 to 15% production gains, lower stack and shell temperatures, more uniform tube-wall temperatures, and ROI typically under a year. Documented examples on this site: a Texas ethylene cracker (Huntsman) cut fuel 12%; an Australian ammonia reformer (CSBP) lifted production 5% and brought bridge-wall temperatures below alarm; a gas-fired process boiler (Apache Nitrogen) produced 15 to 20% more steam on 4 to 5% less gas; a Korean shot-quench furnace (Seoul Shot) saved 10.7% fuel and raised production 16.6%. Energy Savings Production Increase Case Study Library
- 500+
- Facilities coated worldwide
- Up to 15%
- Fuel savings
- 5 to 15%
- Production gains
- Under a year
- ROI, typically
09
Emissivity values of common thermal equipment materials
| Surface | Typical emissivity | With Emisshield |
|---|---|---|
| Ceramic fiber (blanket, module, board) | ~0.3 | 0.85 to 0.95 |
| Refractory brick / castable | ~0.4 | 0.85 to 0.95 |
| Metals in oxidized service (tubes, rolls, tips, shells) | ~0.6 | 0.85 to 0.95 |
FAQ
Frequently Asked Questions
- What is a high emissivity coating?
- A thin ceramic coating engineered to raise a surface's emissivity close to black-body behavior (0.85 to 0.95) and keep it there at extreme temperature, so the surfaces of heaters, boilers, kilns, and vessels re-radiate heat into the product instead of losing it.
- Is a high emissivity coating the same as insulation?
- No. Insulation slows heat leaving through the walls (conduction). A high emissivity coating changes what happens to heat inside the chamber (radiation). Thermal assets need both; they solve different losses.
- How much fuel can a high emissivity coating save?
- Documented Emisshield results range up to 15% depending on asset, fuel, and baseline condition, with sourced cases at 5% (sulfur furnace), 6% (Eastman ethylene furnace), 10.7% (Seoul shot-quench furnace), and 12% (Huntsman ethylene cracker). See Energy Savings.
- Does the effect fade over time?
- Emisshield is a ceramic that bonds above 5,000 PSI and survives thermal shock from -392°F to 2,732°F in 3 seconds without failure. Sustained performance of 36+ months is documented on a glass furnace crown, and more than 7 years on coated process tubes.
- Why does constant emissivity at temperature matter?
- Because most materials' emissivity collapses as they approach operating temperature. The published room-temperature value is not what the asset sees at 2,000°F. Emisshield's value holds to 3,100°F.
- Does it work on metal as well as refractory?
- Yes. Metal-substrate formulations are applied to radiant tubes, burner tips, rolls, water-cooled panels, structural steel, and flare tips, and refractory and fiber formulations to linings. See Products.
